Old style TPS connector 1984-1993 pn #65 ( located on the right side of the throttle body, passenger side).
O2 connector, sensor end pn #13
IAT connector 1992 and up GM pn #11 (located in the air duct).
ALDL Connector all GM vehicles 1984-1995 Y-Body 1984-1995 pn #40
The intended purpose for this connector is to convert the old style coil (4 Pin) over to the 1996-99 three pin coil. Vortec style. pn #2000
Coil connector for the LS1 1998 pn #21
Ground lug 3 wire pn #14
Ground lug 2 wire pn #19
Battery power fuse-able link pn #4500 (location, on any battery power feed).
Oil pressure switch connector pn #18 (location, left side of the engine (driver) oil filter region).
Heated O2 connector pn #28 (location, left or right depending on application).
New style IACV on all 1994 – 2001 F-Body cars pn #75 (location, left side of the LS1 throttle body).
New style VSS standard transmission vehicles 1993-Now pn #12
with the order and we will be happy to take credit card payment over the phone.
